1、現場調查
1. Field investigation
先勘察施工現場，檢查基面情況，要求基面平坦、密集。 對于不符合要求的基本方面，要與相關人員協調，修改基本方面，再次檢查確認。
Survey the construction site first, check the condition of the foundation surface, and the foundation surface shall be flat and dense. For the basic aspects that do not meet the requirements, coordinate with relevant personnel, modify the basic aspects, and check and confirm again.
2、引線
2. Lead
GRC線條需要現場測量相關尺寸。
GRC lines need to be measured on site.
3、圖紙確認
3. Drawing confirmation
根據現場的實際情況，配合設定修訂圖紙，確認產品的尺寸形狀，如有不適當的地方，應立即提出修正意見，向所有者和設定修訂者發送確認。
According to the actual situation of the site, cooperate with the setting revision drawing to confirm the size and shape of the product. In case of any inappropriate place, immediately put forward the correction opinions and send them to the owner and the setting reviser for confirmation.
4、產品制作
4. Product production
GRC生產線產品采用工廠化生產。 工廠應根據工程圖紙，轉換成加工圖，配置詳細的產品加工順序和生產訂單，密切結合現場實際需求安排生產進度。
GRC production line adopts factory production. The factory shall convert the engineering drawings into processing drawings, configure detailed product processing sequences and production orders, and arrange the production schedule in close combination with the actual needs of the site.
5、彈線
5. Snap line
根據施工圖紙，在安裝GRC構件的地方，定位線突出。
According to the construction drawings, the positioning line protrudes at the place where GRC components are installed.
6、線切割
6. Wire cutting
工廠生產的產品都是一定長度，在現場設置時盡量使用一條線，需要切斷的線用專用鋸切鋸。 切面盡量平坦，不平坦的地方要用砂紙磨。
The products produced by the factory are of a certain length. Try to use a line when setting on site, and the line to be cut shall be cut with a special saw. The section shall be as flat as possible, and the uneven part shall be ground with sandpaper.
7、配制灰漿
7. Preparation of mortar
施工中使用的砂漿是根據GRC基礎面的要求特殊調制的專用聚合物粘砂漿。
The mortar used in the construction is a special polymer bonded mortar specially prepared according to the requirements of GRC foundation surface.
施工時應用手持式電動攪拌機攪拌，攪拌充分、均勻、稠度適中。
During construction, hand-held electric mixer shall be used for mixing, with sufficient and uniform mixing and moderate consistency.
砂漿配制完成后，靜置5分鐘，使用前再次攪拌，混煉后的砂漿要在2小時內用完。
After the mortar is prepared, stand for 5 minutes and mix again before use. The mixed mortar shall be used up within 2 hours.
8、貼線
8. Paste line
聚苯乙烯GRC構件膠粘劑使用高質量復合型膠粘砂漿，小型線用全膠粘法粘貼，大型線用點環結合法粘貼，用力按壓GRC構件完全粘貼在壁面上。
Polystyrene GRC component adhesive uses high-quality composite adhesive mortar, small lines are pasted by full adhesive method, large lines are pasted by point ring bonding method, and GRC components are completely pasted on the wall by pressing hard.
9、安裝錨釘
9. Install anchors
在線條的設定部位用錘鉆孔，孔通過GRC線和外壁保溫層，進入基礎壁在50mm以上。 孔的外口略低于內口，以免雨水進入墻體系統。
The set part of the line is drilled with a hammer, and the hole passes through the GRC line and the outer wall insulation layer and enters the foundation wall for more than 50mm. The outer opening of the hole is slightly lower than the inner opening to prevent rainwater from entering the wall system.
10、接縫處理
10. Joint treatment
安裝時請盡量將接縫對準后進行密封。 粘合劑養護24小時后，在接縫處涂上灰漿，立即鋪上寬100mm的耐堿網布或無紡布，再涂上灰漿進行干燥。
During installation, please try to align the joint and seal it. After the adhesive is cured for 24 hours, the joint shall be coated with mortar, and 100mm wide alkali resistant mesh cloth or non-woven fabric shall be immediately paved, and then coated with mortar for drying.
11、線的修補
11. Repair of wire
線條安裝在采用后錨的施工方法的同時，在線條安裝中會(huì )出現接觸或破損的現象，清掃修理的部位，用GRC板材切斷成與缺損部位相同體積和形狀的GRC材料，用專用粘合劑粘貼，在表面涂抹砂漿和耐堿網布，蓋在周邊50mm以上。
When the construction method of rear anchor is adopted for line installation, there will be contact or damage during line installation. Firstly, clean the repaired parts, cut GRC materials with the same volume and shape as the damaged parts with GRC plates, paste them with special adhesive, apply sand slurry and alkali resistant mesh cloth on the surface, and cover them more than 50mm around.
